Jib Crane

Hindustan Hoist & Cranes Industries manufactures and supplies Jib Cranes designed for efficient lifting and movement of materials within workshops, production areas, warehouses and industrial plants.

Jib Cranes provide localized lifting and handling where a full EOT crane is not required. They can be customized according to lifting capacity, boom length, lifting height and rotation requirement.

Key Features

• Robust and heavy-duty construction

• Compact and space-saving design

• Electric Wire Rope Hoist / Electric Chain Hoist options

• Manual or motorized rotation

• Smooth lifting and lowering

• 180° / 270° / 360° rotation options

• Fixed, wall-mounted and pillar-mounted configurations

• Easy operation and maintenance

• Customized boom length and lifting height

• Suitable for indoor and outdoor applications

Technical Specifications

Parameter Specification

Crane Type Jib Crane

Capacity As per requirement

Boom Length As required

Lifting Height As required

Rotation 180° / 270° / 360°

Hoist Wire Rope Hoist / Chain Hoist

Hoisting Speed As required

Trolley Manual / Geared / Motorized

Slewing Manual / Motorized

Control Pendant / Push Button / Radio Remote

Power Supply 415V, 3 Phase, 50 Hz

Mounting Floor / Pillar / Wall

Duty Class As per application

Customization Available

Types of Jib Cranes

1. Pillar Mounted Jib Crane

A vertical pillar supports the jib boom and provides a dedicated lifting station. Suitable for workshops, machine shops and production areas.

2. Wall Mounted Jib Crane

Mounted directly on a suitable building column or wall structure. It is an excellent space-saving solution where floor-mounted columns are not preferred.

3. Floor Mounted Jib Crane

Installed on a specially designed foundation or floor-mounted pillar. Suitable for independent lifting stations.

4. Motorized Jib Crane

Motorized slewing and/or trolley movement can be provided for applications requiring frequent and controlled operation.

5. Portable / Mobile Jib Crane

Designed for applications where lifting equipment needs to be moved between different work areas, subject to suitable design and load conditions.

Main Components

Jib Boom

Heavy-duty fabricated boom designed to safely support the hoist, trolley and suspended load.

Pillar / Column

The pillar is designed according to the lifting capacity, boom length, foundation and overturning moment.

Hoist

Electric wire rope hoist or electric chain hoist can be selected according to the required capacity and lifting height.

Trolley

Manual, geared or motorized trolley arrangements are available for horizontal movement along the boom.

Slewing Mechanism

The jib can be manually or electrically rotated according to the required working area.

Foundation

For floor-mounted jib cranes, the foundation and anchoring arrangement are designed according to the crane loads and site conditions.

Safety Features

Depending on the application, Jib Cranes can be equipped with:

• Upper & lower hoist limit switches

• Hoist overload protection

• Emergency stop

• Fail-safe brake

• Slewing limit arrangement

• Trolley travel limits

• Motor thermal protection

• Phase failure protection

• Safety hook latch

• VFD control, where required

Applications

Jib Cranes are widely used in:

• Engineering Industries

• Automobile Industries

• Fabrication Shops

• Machine Shops

• Assembly Lines

• Manufacturing Plants

• Warehouses

• Maintenance Workshops

• Tool Rooms

• Foundries

• Steel Industries

• Loading & Unloading Areas

• Machinery Handling

• Workstation Material Handling

Advantages of Jib Cranes

Space Saving

Provides lifting facilities at specific workstations without requiring a complete EOT crane system.

Easy Operation

Simple and efficient movement of materials within the jib's working radius.

Flexible Configuration

Available with different mounting, rotation, trolley and hoist arrangements.

Customized Design

Capacity, boom length, lifting height and rotation can be designed according to application requirements.

Customized Jib Crane Solutions

We design Jib Cranes according to:

Capacity + Boom Length + Lift Height + Working Radius + Rotation + Hoist Type + Duty Class

Our technical team can recommend a suitable configuration based on your application and available installation space.

Why Choose Hindustan Hoist & Cranes Industries?

• Since 2006

• Experienced crane engineering and fabrication

• Customized lifting solutions

• Heavy-duty construction

• Quality components

• Installation & commissioning support

• Preventive maintenance

• AMC & after-sales service
